Paracaidas de seguridad para prensa hidráulica KR, K series

hidráulico para carga en compresión

Dispositivos anticaída Retención elevada segura en caso de producirse una caída de presión Protección de personas y prevención de accidentes Los dispositivos anticaída se emplean para evitar la caída o el descenso accidental de cargas pesadas elevadas. Serie K, KR, KRP ... Para cargas medianas, grandes y muy grandes Homologación DGUV Una dirección de carga Technical Data Sheet TI-A11 Safety Catchers sériés KR (with dguv approvai) Load direction compressive (to mounting surface) General information, particularly regarding purpose, function, choosing the right type, attachment and control is provided in "Technical Information TI-A10". Further important practical advice is given in "Operating Manual BA-A11”. O M is the admissible load the mass to be secured exerts on the Safety Catcher. The holding (braking) force for dry or hydraulic-oil wetted rods is not less than 2 x M but will not exceed 3.5 x M. © The necessary pressure to keep the clampmg released is 40 bar. In case a spring base is installed. the required pressure for releasing without lifting is 60 bar. see “Techmcal Data Sheet TI-A20'. The admissible operating pressure ts 250 bar. © As supplied. pressure port LL is plugged by a plug screw. It may be used alternatively to pressure port L and is useful for filling / air-bleeding. We recommend to install an auto-bleeder at port LL (or L) as descnbed in “Technical Information TI-Z10".
